JLL2200

Home » Products » GENERATOR

Generator Rating frequency(Hz) 50 60 50 60 50 60 50 60 50 60
Rating Voltage(V) 110/120/220/230/240
Rating power(KVA) 2.0 2.5 2.5 2.7 2.8 3.6 4.0 4.5 5.0 5.5
The Max.power(KVA) 2.2 2.7 2.7 3.0 3.0 4.2 4.8 5.0 5.5 6.0
Power factor(cos) 1.0
Engine Type 168F 168F-1 177F 182F 188F
Category Single crock,Force air-cooled four-stroke,top-intalled gasoline engine
Exclusion of cylinder(cm3) 163 196 270 337 389
The Max.output power(KW/rpm) 4.8/3600 5.7/3600 7.0/3600 8.0/3600 9.5/3600
Ignition system Transistorized magneto
Start system Recoil/E-start
Capacity of fuel tank(L) 15 15 25 25 25
Consumption of fuel(L/h) 1.13 1.32 1.9 2.45 2.70
Consecutive Working(h) 13 11 13 10 9
Noise(at7m)(dB) 65 65 69 72 74
Capacity of engine oil 0.6 1.1
Dimension Set                        dimension(mm3) 615×435×455  615×435×455           620×470×480 635×510×485 670×510×510
Net weight(kg) 39 40 62 78 80
Standard Equipment Large capacity fuel tank,large capacity muffler,fuel gauge,voltmeter,AVR,oil alert,Ac circuit breaker
Purchasing Four-wheel dolly kit Yes
